- Quantity: 1 pcs
- Wheelbase: Screws
- Size: 32X24X 7
- Technical parameters: Value 2
- Model Number: XXD 10A 30A 40A
- For Vehicle Type: Airplanes
- Tool Supplies: Governor
- Four-wheel Drive Attributes: Motors
- Remote Control Peripherals/Devices: ESC
- Upgrade Parts/Accessories: Brushless ESC
- RC Parts & Accs: Spinners
- Material: Metal
- Brand Name: U-Angel-1988
- Origin: Mainland China
- Recommend Age: 14 y
- Use: Vehicles & Remote Control Toys
- is_customized: Yes
Continuous current: 30A
Instant: 35A, 40A for 10 seconds.
Dimensions/weight: 32X24X 7 (mm) 13g (without wire) 20g (with wire)
Voltage range: 4V-16V
Number of batteries: 4-12NIMH, 2-3LIPO (4LIPO does not allow the use of BEC output)
BEC output: continuous 2A, (instantaneous 3A)
2LIPO 4- 5 micro steering gear
3LIPO 3-4 micro steering gear
Protective function: .
Automatically select 2-3LIPO, the protection voltage is 6V/9V;
Automatically select NIMH, each protection voltage is 0.8V;
Safe start, the throttle position is wrong to prohibit start;
Temperature protection, 110 degree surface temperature shutdown;
Out of control protection, stop after 1 second without signal.
Performance description:.
The upper limit of rotation speed is up to 300,000 rpm in 2 poles, 50000 rpm in 12 poles, and 42000 rpm in 14 poles.
8KHz PWM control, using speed control curve.
Automatic throttle adaption, suitable for more remote control equipment.
Using BEC, the MCU separates the power supply and the work is more stable.
